ESP32-CAM WiFi + Bluetooth Camera Module Development Board ESP32 With Camera Module OV2640 and Base

ESP32-CAM WiFi + Bluetooth Camera Module Development Board ESP32 With Camera Module OV2640 and Base

Key Features:

• High-Quality Camera: Equipped with the OV2640 camera module, which delivers a 2MP image resolution of up to 1600x1200 pixels, suitable for capturing high-quality still images and video streams.

• Dual Connectivity: The ESP32 chip integrates both WiFi and Bluetooth (Classic & BLE), offering versatile wireless communication options for your IoT projects.

• Base Board with GPIOs: Comes with a base board that provides multiple GPIO pins (up to 22) for connecting external sensors, actuators, or additional modules to expand your project.

• Micro USB Interface: The base board includes a Micro USB port for easy power supply and programming, eliminating the need for an external programmer.

• Flash Memory: Includes 4MB flash memory, ideal for storing firmware and camera-related applications.

• Low Power Consumption: The ESP32 features a variety of power-saving modes, making it ideal for battery-operated and energy-efficient devices.

• Video Streaming: Supports JPEG compression for video streaming and image capture, making it suitable for applications such as live video monitoring or remote surveillance.

• Built-in Antenna: Features a PCB antenna for WiFi and Bluetooth communication without requiring additional external antennas.

• Onboard SD Card Slot: The base board provides an SD card slot for additional storage, allowing you to save images and videos directly from the camera.

Applications:

• Wireless camera surveillance systems

• Face detection and recognition systems

• Remote monitoring and security systems

• IoT-based video streaming

• Smart home automation (e.g., doorbell cameras)

• Environmental and wildlife monitoring

• Robotics and drone cameras

Technical Specifications:

• Microcontroller: ESP32 Dual-Core Processor (up to 240 MHz)

• Camera Module: OV2640 (2MP, up to 1600x1200 resolution)

• WiFi: 802.11 b/g/n

• Bluetooth: Bluetooth 4.2 (Classic & BLE)

• Base Board: Includes multiple GPIOs (up to 22)

• Flash Memory: 4MB

• SD Card Slot: Supports microSD cards for additional storage

• USB Port: Micro USB for power and programming

• Camera Features: JPEG compression, video streaming, real-time capture

• Antenna: Onboard PCB antenna for wireless connectivity

• Power Supply: 5V via Micro USB

• Operating Voltage: 3.3V

• Programming Environment: Arduino IDE, ESP-IDF, MicroPython

Why Choose the ESP32 Camera with Base Board?

• Dual Connectivity (WiFi and Bluetooth) for wireless communication in IoT applications.

• High-quality camera module for detailed image and video capture, ideal for real-time streaming and monitoring.

• Easy to program and integrate with the Arduino IDE, making it user-friendly for both beginners and professionals.

• Versatile GPIO pins allow you to connect various sensors and actuators, expanding the project’s functionality.

• Low power consumption features, ideal for battery-powered applications and energy-efficient designs.

• Onboard SD card slot enables additional storage for images, videos, and logs.

• Compact and cost-effective solution for integrating camera functionality into your projects.

The ESP32 Camera with Base Board provides all the necessary tools to build IoT-based camera systems, from security cameras to robotics and remote monitoring. Its dual connectivity, high-quality imaging, and easy programming make it an ideal choice for developers and makers looking to add camera functionality to their wireless projects.
