Key Technological Advancements

✔ Ultra-Precision Measurement Core

• DC Voltage: ±(0.002% of reading + 0.0003% of range)

• Resistance: ±0.003% with 0.01mΩ resolution

• Advanced thermal management system (±0.5ppm/°C drift)

✔ Dual-Channel Smart Measurement

• Independent dual displays with configurable layout

• Simultaneous AC/DC or V/I measurements with 1MS/s sampling

✔ Future-Ready Connectivity

• Standard: USB-C (USB-TMC), Ethernet (LXI Class C), Bluetooth 5.0

• Optional: GPIB (IEEE-488.2) and RS485 for industrial environments

✔ Intelligent Features

• On-board harmonic analysis (up to 100th order)

• Graphical trend display with touch zoom

• Auto-calibration reminder system

Technical Specifications

Measurement Capabilities

Enhanced System Features

• Display: 7" capacitive touchscreen (1280×800) with multi-touch support

• Memory: 2GB internal storage (expandable via USB)

• Protection: Category III 1000V/CAT IV 600V rated

• Compliance: Meets IEC 61010-1, ISO 17025 standards

What's Included

• Main unit with universal power adapter (90-264VAC)

• UT-L24 gold-plated precision test leads (1 pair)

• 4-wire Kelvin probes

• Type K thermocouple (Class A)

• USB-C to USB-A/C cables

• NIST-traceable calibration certificate with uncertainty analysis

Why Upgrade to UT8804E?

1. 30% Higher Accuracy than previous UT8802E model

2. 10x Faster Sampling for dynamic measurements

3. Wireless Operation via Bluetooth smartphone control

4. 5-Year Extended Warranty option available

Professional Applications: • Metrology laboratories • Semiconductor characterization • Power quality analysis • Automotive ECU testing

Optional Accessories:

• High-stability reference module (±1ppm)

• Automated test software package

• Rackmount kit (2U standard)

• Environmental monitoring probe
