DS26LS31 quad differential line driver
In Stock
Categories: Integrated Circuits, Other ICs
Overview
The DS26LS31 is a high-speed quad differential line driver designed for digital data transmission over long distances and in noisy environments. It features four independent line drivers, each capable of driving balanced lines such as those used in RS-422 and RS-485 communication systems.
Engineered for low power consumption and high noise immunity, the DS26LS31 ensures reliable, high-speed data transmission, making it ideal for industrial automation, instrumentation, and communication applications.
Description
Parameters:
Number of receivers: 0.
Number of transmitters: 4.
Duplex: Half.
Supply voltage (Nom) (V): 5V.
Signaling rate (Max) (Mbps): 10.
IEC 61000-4-2 contact ( /- kV): None.
Fault protection (V): -0.5 to 7.
Common mode range: -7 to 7.
Number of nodes: 32.
Isolated: No.
ICC (Max) (mA): 60.
Rating: Catalog.
Operating temperature range (C): 0 to 70.
features:
- Output Skew—2.0 ns Typical.
- Input to output delay—10 ns Typical.
- Operation from Single 5V Supply.
- Outputs Won't Load Line when VCC = 0V.
- Four Line Drivers in One Package for Maximum Package Density.
- Output Short-Circuit Protection.
- Complementary Outputs.
- Meets the Requirements of EIA Standard RS-422.
- Pin Compatible with AM26LS31.
- Available in Military and Commercial Temperature Range.
package included:
1 X DS26LS31 quad differential line driver.
