MAX516 DIP Integrated Circuit

Electra Store SKU: CM-21694

85.00 EGP

In Stock

Quantity

Share to

Overview

The MAX516 is a compact, digitally controlled electronic potentiometer (digipot) IC that replaces traditional mechanical variable resistors. It is ideal for applications requiring digital control of resistance, such as calibration, tuning, volume adjustment, or analog signal scaling. The device features non-volatile memory, allowing it to retain settings after power is removed.

Description

🔧 Key Features:

Digitally Controlled Potentiometer
8-bit Resolution – 256 Wiper Positions
Total Resistance Options: Common values include 10kΩ, 50kΩ, 100kΩ (check part suffix)
Non-volatile EEPROM memory stores wiper position
Up/Down Control or Serial Interface (varies by model)
Operates from a Single +5V Supply
Low Power Consumption

📦 Technical Specifications:

Power Supply: +2.7V to +5.5V
Interface Type: Up/Down control or 3-wire digital (depending on version)
Wiper Resistance: Typically 400Ω
Temperature Range: 0°C to +70°C (Commercial)
End-to-End Resistance Tolerance: ±20%

⚙️ Applications:

Digital volume control
LCD contrast and brightness control
Offset and gain adjustment
Programmable filters
Calibration of sensor circuits
Replacing mechanical potentiometers in embedded systems

📝 Notes:

The MAX516 is ideal for use in systems where automated or remote adjustment of resistance is needed.
No mechanical wear, making it more reliable than traditional trimmers or pots.
Retains its last resistance value even after power-down (non-volatile models).
