UNI-T UT387S Wall Scanner
Electra Store
SKU: UT-3876
4,000.00 EGP
4,000.00 EGP
Save 0%
Out of Stock
Categories: Measuring Devices, UNI-T
Overview
UNI-T UT387S Wall Scanner for Measuring Distance and Wood Moisture
UNI-T UT387S wall scanners are used to detect a variety of objects behind the wall, designed with multiple measurement modes and additional function to conveniently measure the laser distance and wood moisture detection. They are widely used in home renovation, home improvement and DIY projects.
Features of UT387S Wall Scanners
Certificates: CE, UKCA
● 2.4-inch color screen
● Voice broadcast
● Li-ion battery
● Auto power off
● Multiple measurement modes
Description
UNI-T UT387S Wall Scanner for Measuring Distance and Wood Moisture
- This product can detect metals (rebars, copper pipes), cables, and woods hidden In walls, ceilings, floors, and under gypsum boards.
- This product can be used for laser distance measurement, which can measure the length, area, and volume of houses.
- This product can measure the moisture of all kinds of wood and building materials.
Product Structure
UNI-T UT387S structure
Notes: Please use a safe charger and cable with a Type-C USB interface, a voltage output of 5V, and a current of ≥500mA. The company is not responsible for accidents caused by the charger.| No. | Description |
| 1 | Receiving lens aperture for distance measurement. |
| 2 | Laser aperture for distance measurement |
| 3 | LED indicator |
| 4 | 2.4-inch color screen |
| 5 | Buttons |
| 6 | Probe for moisture detection |
| 7 | Probe cover |
| 8 | Sensor area (objects around it will be detected) |
| 9 | Label |
| 10 | 1/4 copper nut |
| 11 | The protective cover of the Type-C USB charging interface |
| 12 | Loudspeaker |
UNI-T UT387S buttons
a. foreign material detection (wooden beam) b. long press to power on. After the product is turned on: short press: single measurement long press: continuous measurement. c. Metal detection d/f. Enter/select the distance measurement menu. e. long press to power off g. short press to switch between: Detect the moisture/lock the moisture data. h. Clear.
UNI-T UT387S Specifications |
|
| Wood scanning depth (precision mode) * | 20mm |
| Wood scanning depth (depth mode) * | 38mm |
| Metal scanning depth* | 100mm |
| Non-ferrous metal scanning depth’ | 80mm |
| Live wire alarm accuracy’ | Live 110-220V, 50-60Hz. 50mm |
| Copper wire (?:4mm2) | 40mm |
| Auto calibration | 0. |
| Operating temperature | 0-40°C |
| Operating humidity | Metal mode: 0-85%RH |
| AC mode: 0-30%RH | |
| Wooden beam mode: 0-60%RH | |
| Storage temperature | -20-60°C |
| Drop-proof | 1m |
| LCD | 2.4-inch color screen |
| Auto power off | About 5min |
| Battery | 300mAh lithium battery |
| Battery life | 3000 single measurements |
| Shutdown current | 0 mA |
| Audio alarm | Voice broadcast |
| Low battery indication | 4 |
| Distance measurement parameters | |
| Accuracy | ± (2.0mm 5 x 1 0-5D) |
| Unit | m/ft in |
| Range | 0.05-40m |
| Laser auto off | the 20s |
| Data storage | 30 groups |
UNI-T UT387S Distance Measurement
| 1. Battery status 2. Measurement reference 3. Measurement mode | 4. Secondary display 5. Primary display |
-
UNI-T UT387S Single measurement:
-
UNI-T UT387S Continuous measurement:
-
Menu:
-
UNI-T UT387S Addition measurement:
-
UNI-T UT387S Subtraction measurement:
-
UNI-T UT387S Area measurement:
-
UNI-T UT387S Single Pythagorean measurement:
-
UNI-T UT387S Double Pythagorean measurement:
-
UNI-T UT387S Historical measurement data:
-
Reference setting:
-
Voice broadcast off/on:
Error Code
| No. | Error code | Error reason |
| 1 | ERROR | No error |
| 2 | ERRO1 | Battery voltage <2.2V |
| 3 | ERRO2 | Internal error, ignore |
| 4 | ERRO3 | Low temperature ( < -20°C) |
| 5 | ERRO4 | High temperature ( >40t ) |
| 6 | ERRO5 | Over range |
| 7 | ERRO6 | Invalid measurement result |
| 8 | ERRO7 | Strong ambient light |
| 9 | ERRO8 | Weak signal |
| 10 | ERRO9 | Strong signal |
| 11 | ERR10 | Internal hardware failure 1 |
| 12 | ERR11 | Internal hardware failure 2 |
| 13 | ERR12 | Internal hardware failure 3 |
| 14 | ERR13 | Internal hardware failure 4 |
| 15 | ERR14 | Internal hardware failure 5 |
| 16 | ERR15 | Unstable laser signal |
| 17 | ERR16 | Internal hardware failure 6 |
| 18 | ERR17 | Internal hardware failure 7 |
| 19 | ERR18 | Invalid frame |
Safety Information
Before using this product, please read this manual carefully. Otherwise, it may result in laser radiation, electric shock, or personal injury.
Do not change the performance of the laser in any way. It will cause dangerous laser exposure. Turn on the laser only when using this product, and do not look directly at the laser. Please keep the product in a safe place so as not to use it by irrelevant personnel. Do not direct the laser beam at persons deliberately or in the dark. Do not irradiate the laser beam on objects with highly reflective surfaces. Do not place the product where children can reach.
Do not repair this product without authorization. If it is damaged, please contact the local dealer.
Electromagnetic radiation may cause interference to other devices (such as pacemakers or hearing aids and other medical instruments).
Do not use this product in a flammable and explosive environment, near medical equipment, or on an airplane.
Please dispose of the obsolete instrument in accordance with the local laws and regulations.
package included:
1 X UNI-T UT387S Wall Scanner. ElectraCustomer Reviews
