TB6560 Stepper Motor Driver
Electra Store
SKU: MD-22661
550.00 EGP
Out of Stock
Categories: Motor Drivers
Overview
TB6560 Stepper Motor Driver
Description
Stepper Motor Driver
Features:
- TB6560 Single-chip bipolar sinusoidal micro-step stepping motor driver
- Forward and reverse rotation control available
- Selectable phase drive (2, 1-2, W1-2, and 2W1-2)
- High output withstand voltage: VCEO = 40 V
- High output current: IOUT = HQ: 3.5 A (peak)
- Built-in input pull-down resistor: 100 kΩ
- Output monitor pin equipped: MO current (IMO (max) = 1 mA)
- Equipped with reset and enable pins
- Built-in overheat protection circuit
- Operating Voltage: 5-36V " Set it according to the motor " For Nema 17 recommended 12v
- For the TB6560 datasheet, please click here
