JCS18N50FH – 18A / 500V Power MOSFET (TO-220F Package)

Electra Store SKU: EL-70086

60.00 EGP

In Stock

Quantity

Share to

Overview

The JCS18N50FH is a high-voltage, high-current N-channel MOSFET designed for switching and amplification applications in power electronics. With a drain-source voltage rating of 500V and continuous drain current of 18A, it offers excellent performance for demanding AC and DC circuits. Housed in a fully insulated TO-220F package, it ensures safe, compact, and efficient mounting without the need for additional insulation hardware.

Description

Key Features:

High Current Capability: Supports continuous drain current up to 18A.
High Voltage Rating: Withstands drain-source voltage (Vds) up to 500V.
Low On-Resistance (Rds(on)): Improves efficiency and reduces power loss.
Fast Switching Speed: Ideal for high-frequency power conversion.
Fully Isolated TO-220F Package: Provides electrical isolation between the semiconductor and heatsink.
Enhanced Reliability: Rugged construction for long operational life.

Typical Applications:

Switched-Mode Power Supplies (SMPS)
Motor Drivers and Control Circuits
Power Inverters and Converters
Lighting Ballasts and LED Drivers
Uninterruptible Power Supplies (UPS)

Electrical Specifications:

Drain-Source Voltage (Vds): 500V
Continuous Drain Current (Id): 18A
Gate Threshold Voltage (Vgs(th)): ~2-4V
Maximum Power Dissipation (Pd): ~150W (depending on heatsink)
Package Type: TO-220F (Fully Insulated)

The JCS18N50FH offers a balance of high voltage, high current, and efficiency—making it an excellent choice for engineers designing robust and energy-efficient power electronics.
