IRF9630 P-Channel Power MOSFET – TO-220

Electra Store SKU: CM-22031

25.00 EGP

Out of Stock

Share to

Overview

The IRF9630 is a high-voltage, high-current P-Channel Power MOSFET designed for efficient switching and power management applications. It features low on-resistance and fast switching speed, making it ideal for power supplies, DC-DC converters, and load switching circuits. Its TO-220 package ensures excellent thermal dissipation and easy mounting.

Description

✅ Key Features:

Drain-Source Voltage (Vds): -200V
Continuous Drain Current (Id): -12A @ 25°C
RDS(on): 0.15 Ohm (max)
Gate Threshold Voltage (Vgs(th)): -2.0 to -4.0V
Total Power Dissipation (Pd): 150W
Package Type: TO-220
Fast Switching Speeds
Low Gate Drive Voltage
Robust and Durable Construction

🔧 Typical Applications:

High-side load switching
Power management circuits
DC-DC converters
Battery protection
Audio amplifier output stages
General power switching and control

📦 Technical Specifications:

Parameter	Value
Type	P-Channel MOSFET
Maximum Drain-Source Voltage (Vds)	-200V
Maximum Continuous Drain Current (Id)	-12A
Maximum RDS(on)	0.15 Ohm
Gate Threshold Voltage (Vgs(th))	-2.0 to -4.0V
Maximum Power Dissipation (Pd)	150W
Package	TO-220

⚠️ Note:

Proper heatsinking is important for reliable operation under high power conditions.

The IRF9630 is an efficient and reliable P-Channel MOSFET suitable for demanding power switching and control applications in professional and hobbyist electronics.
