IRF1404 N-Channel Power MOSFET – TO-220 Package
In Stock
Categories: Transistors
Overview
Description
✅ Key Features:
-
Drain-Source Voltage (Vds): 40V
-
Continuous Drain Current (Id): 202A @ 25°C
-
RDS(on): 0.0053 Ohm (max)
-
Gate Threshold Voltage (Vgs(th)): 1.0 – 2.0V
-
Total Power Dissipation (Pd): 330W
-
Package Type: TO-220
-
Ultra Low On-Resistance for High Efficiency
-
Fast Switching Speed
-
Low Gate Drive Requirements
-
High Current Capability
🔧 Typical Applications:
-
Automotive electronics (especially low-voltage motor drives)
-
High-current DC-DC converters
-
Power tools and inverters
-
Synchronous rectification
-
Battery-powered systems
-
Load switching and protection circuits
📦 Technical Specifications:
| Parameter | Value |
|---|---|
| Type | N-Channel MOSFET |
| Vds (Max) | 40V |
| Id (Max) | 202A |
| Rds(on) (Max) | 0.0053 Ohm |
| Vgs(th) | 1.0 – 2.0V |
| Package | TO-220 |
| Power Dissipation (Max) | 330W |
⚠️ Note:
Due to its high current capability, adequate heatsinking and PCB copper area are essential for safe and reliable operation.
