DC Motor with Gear Box JGA25-370-12V-133RPM 20Kg.cm
Electra Store
SKU: GA-25370
360.00 EGP
Out of Stock
Overview
A 12V DC motor, almost double the power of our 6V DC motor.
This easy-to-mount JGA25-370 DC gearmotor is great for building robots and it comes in a variety of configurations that suit even the most exigent designs.
This motor features a D-shaped output shaft.
It is a powerful motor fitted with a 75:1 metal gearbox.
The gears are all steel and the output shaft is 4mm diameter.
The motor has extra rear shaft (on the high-speed side, before the gearbox) which allow you to mount motor encoder for RPM counting and superior control.
Description
Specifications
- Operating voltage: between 6 V and 18 V
- Nominal voltage: 12 V
- Free-run speed at 12 V: 133 RPM
- Free-run current at 12 V: 50 mA
- Stall current at 12 V: 1200 mA
- Stall torque at 12 V: 20 kg.cm
- Gear ratio: 1:78
- Reductor size: 21 mm
Package Included:
1 X DC Motor with Gear Box JGA25-370-12V-133RPM 20Kg.cm ElectraCustomer Reviews
