4.8-6V Servo Tester CCPM Consistency Master Checker with Rev

Electra Store SKU: MD-26601

55.00 EGP

Out of Stock

Share to

Categories: Motor Drivers

Overview

CCPM Servo Consistency Tester

Description

Servo Consistency Tester

CCPM Servo Consistency Master/Servo tester. The device also can be used as a signal generator for electric speed controller (ESC). With it, you can test your motor system without using a transmitter and receiver Output: 15mA (5.0) Voltage consumption: DC4.8-6V Output signal: 1.5ms±0.5ms Product size: 44 x 30 x 23mm Product weight: 5g Features: There are 3 modes to check servos or ESC:

Manual mode: turn the knob with different speed, check the reaction time;
Neutral mode: make the servo go back to the neutral point;
Automatic: “window wiper” mode: make the servo swing like a window wipers in the biggest angle.

It can connect 1-3 servos simultaneously and test such as 1-3 servos consistency and so on. You can also connect 1-3 ESC to test and compare their reaction time respectively. It can connect 3 servos of the CCPM helicopters and select servos. It can also connect the servo of airplanes install the steering-box and adjust planes by using such as the neutral mode and so on. With LED indicators.
